Stainless Steel Sheet Metal Fabrication Services

Tolerance Accuracy

Structure Level Tolerance

Tolerance range: ±0.5 to ±2 mm — suitable for non-precision components such as frames and brackets. This level of tolerance can be achieved using conventional Laser Cutting and Sheet Metal Bending processes, making it ideal for high-volume, cost-effective production.

Mating Grade Tolerance

Tolerance range: ±0.1 to ±0.5 mm — ensures precise assembly of parts. Higher-precision equipment such as Sheet Metal Laser Cutting and CNC bending is required to meet the assembly standards for electrical cabinets and similar products.

Precision Grade Tolerance

Tolerance range: ±0.01 to ±0.1 mm — used in high-end applications. Achieved through advanced technologies like Precision Laser Cutting and 5-Axis CNC Milling, enabling micron-level accuracy control.

Shipment & Packaging

Precision Parts Packaging

Each part is individually secured in a custom anti-static blister box. Desiccant packets are included inside the package, and warning labels are clearly marked on the outside to ensure safe and secure transportation.

Packaging of Large Structural Parts

Custom wooden frames are used to securely hold large structural components. Welded sections are protected with sleeves, and the surface is covered with dust-proof cloth. Lifting points are clearly labeled to ensure stability and safety during transport.
